## Introduction to Matlab boolean

MATLAB Boolean operators are used to return logical values (True for 1 and False for 0) in case we want to check if a condition is met or not. Boolean operators are very useful in codes where we need to execute code lines based on certain conditions.

For example, we can compare 2 numbers using logical operators and get True in the output if the numbers are equal else False.

**Syntax:**

Logical AND (&), OR (|), NOT (~) are some of the commonly used Boolean operators.

### How to use Matlab boolean with Examples?

Let us now understand how to use logical or Boolean operators in MATLAB. We will discuss 2 scenarios:

- The use of Boolean operators in arrays
- The use of Boolean operators in circuits

#### Example #1

In this example, we will use an ‘&’ operator between 2 matrices. An ‘&’ operator will give ‘1’ as the output if the corresponding elements in both the matrices are non-zero, else it will give ‘0’ as the output. The steps to be followed for this example are:

- Initialize the input matrices
- Use the ‘&’ operator between the matrices

**Code:**

```
A = [5 4 1; 5 2 0; 1 0 1]
[Initializing the 1
```

^{st} matrix]
B = [0 1 1; 0 0 0; 1 9 3]
[Initializing the 2^{nd} matrix]
A & B

[Using the Boolean operator ‘&’ between the matrices. The output will be a matrix of 0s and 1s]

4.5 (6,961 ratings)

View Course

This is how our input and output will look like in MATLAB:

**Input:**

```
A = [5 4 1; 5 2 0; 1 0 1]
B = [0 1 1; 0 0 0; 1 9 3]
A & B
```

**Output:**

As we can see in the output, the Boolean operator ‘&’ gives ‘1’ as the output if the corresponding elements in both the matrices are non-zero, else it gives ‘0’ as the output

Next, we will see the use of the ‘&’ operator in the circuits

#### Example #2

When used in circuits, the ‘&’ operator will give ‘1’ as the output if both the variables are non-zero, else it will give ‘0’ as the output. The steps to be followed for this example are:

- Initialize the input variables
- Use the if-else loop along with the Boolean ‘&’ operator

**Code:**

`a = 10`

[Initializing the 1^{st} variable]
b = 20

[Initializing the 2^{nd} variable]
c = 0

[Initializing the 3^{rd} variable]
if (a && b)

disp(‘Both the numbers are non-zero’);

else

disp(‘Both the numbers are not non-zero’);

end

[This loop with Boolean ‘&’ operator will check if both the variables are non-zero; In this example we have taken both ‘a’ and ‘b’ as non-zero]
if (a && c)

disp(‘Both the numbers are non-zero’);

else

disp(‘Both the numbers are not non-zero’);

end

[This loop will check if both the variables ‘a’ and ‘c’ are non-zero]

This is how our input and output will look like in MATLAB:

**Input:**

`a = 10`

b = 20

c = 0

if (a && b)

disp('Both the numbers are non-zero');

else

disp('Both the numbers are not non-zero');

end

if (a && c)

disp('Both the numbers are non-zero');

else

disp('Both the numbers are not non-zero');

end

**Output:**

- In the 1
^{st}loop, both the variables ‘a’ and ‘b’ are non-zero, so the output after using Boolean ‘&’ operator is “Both the numbers are non-zero” - In the 2
^{nd}loop, the variables ‘a’ is non-zero, whereas the variable ‘c’ is zero, so the output after using Boolean ‘&’ operator is “Both the numbers are not non-zero”

#### Example #3

In this example, we will use an ‘|’ (OR) operator between 2 matrices. An ‘|’ operator will give ‘1’ as the output if any one of the corresponding elements in the matrices is non-zero, else it will give ‘0’ as the output. The steps to be followed for this example are:

- Initialize the input matrices
- Use the ‘|’ operator between the matrices

**Code:**

```
A = [2 4 6; 2 2 0; 3 0 7]
[Initializing the 1
```

^{st} matrix]
B = [0 4 1; 1 0 0; 2 0 3]
[Initializing the 2^{nd} matrix]
A | B

[Using the Boolean operator ‘|’ between the matrices. The output will be a matrix of 0s and 1s]

This is how our input and output will look like in MATLAB:

**Input:**

```
A = [2 4 6; 2 2 0; 3 0 7]
B = [0 4 1; 1 0 0; 2 0 3]
A | B
```

**Output:**

As we can see in the output, the Boolean operator ‘|’ gives ‘1’ as the output if any one of the corresponding elements in the matrices is non-zero, else it gives ‘0’ as the output.

Next, we will see the use of the ‘|’ operator in the circuits

#### Example #4

When used in circuits, the ‘|’ operator will give ‘1’ as the output if any one of the variables is non-zero, else it will give ‘0’ as the output. The steps to be followed for this example are:

- Initialize the input variables
- Use the if else loop along with the Boolean ‘|’ operator

**Code:**

`a = 0`

[Initializing the 1^{st} variable]
b = 10

[Initializing the 2^{nd} variable]
c = 0

[Initializing the 3^{rd} variable]
d = 0

[Initializing the 4^{th} variable]
if (a || b)

disp(‘At least one of the numbers is non-zero’);

else

disp(‘Both the numbers are zero’);

end

[This loop with Boolean ‘|’ operator will check if any one of the variables is non-zero; In this example we have taken ‘a’ as zero and ‘b’ as non-zero]
if (c || d)

disp(‘At least one of the numbers is non-zero’);

else

disp(‘Both the numbers are zero’);

end

[This loop will check if one of the variables ‘c’ and ‘d’ is non-zero]

This is how our input and output will look like in MATLAB:

**Input:**

`a = 0`

b = 10

c = 0

d = 0

if (a || b)

disp('At least one of the numbers is non-zero');

else

disp('Both the numbers are zero');

end

if (c || d)

disp('At least one of the numbers is non-zero');

else

disp('Both the numbers are zero');

end

**Output:**

- In the 1
^{st}loop, the variable ‘a’ is 0 and ‘b’ is non-zero, so the output after using Boolean ‘|’ operator is “At least one of the numbers is non-zero” - In the 2
^{nd}loop, both the variables ‘c’ and ‘d’ are zero, so the output after using Boolean ‘|’ operator is “Both the numbers are zero”

### Conclusion

- Boolean operators are useful in cases where we want to check if a condition is met or not.
- Boolean operators are also used in circuit codes where we need to execute code lines based on certain conditions.
