What is Proximity Sensors?

Priya Pedamkar
Article byPriya Pedamkar

Updated March 17, 2023

what is proximity sensors

What is Proximity Sensors?

These sensors are used to detect the presence of any object without the need for any physical contact. Electromagnetic radiation is emitted and checks for the changes in the field of the object and the signal. Wilfried Gehl, Walter Pepperl and Ludwig Fuchs invented the first proximity sensor. These are used in parking lots, mobile phones, conveyor systems, and many other places. The three types of proximity sensors are magnetic type, capacitance type and high-frequency oscillation type sensors. The principle is based on the coil and oscillator to create an electromagnetic field in the sensing surface’s surroundings.

Start Your Free Software Development Course

Web development, programming languages, Software testing & others

Top 6 Types of Proximity Sensors

Types of proximity sensors are given below:

1. Inductive Proximity Sensor

The sensor is called inductive because it detects under the electric principle of inductance. It detects metallic objects. It uses the oscillator circuit to generate a high-frequency electromagnetic field. The sensor consists of an inductive loop. When cable comes out of the sensor, it turns red, metal gets detected, and the sensor is switched on. When the cable goes away, the output of the sensor is switched off.

2. Capacitive Sensor

It detects metallic and non-metallic objects in liquid, solid and granulated form.    It operates as an open capacitor because it has two conduction plates are positioned at the sensing head. The capacitance of these two plates increases when an object enters the sensing area, it causes to change oscillator amplitude, Schmitt triggers state changes, and the output signal is created. The capacitive sensor oscillates if the target is present. Charging plates range from 10 to 50 HZ. It detects any type of material; the sensor should be kept away from non-target material to avoid the false trigger.

3. Photoelectric Sensor

It can sense the target within 1mm in diameter. It is a rapidly advanced sensor. It can solve the bulk of industrial sensing objects. It has a laser diode, photodiode receiver to detect emitted light. Supporting electronics are designed to amplify the receiver. To detect the receiver emitter is used because it transmits the beam of visible or infrared light.

4. Through-Beam

It is the most reliable photoelectric sensor. The emitter provides a constant beam of light. Sensing occurs when the object passes the between two breaks the beam. It is separated from the receiver using separate housing. It is reliable to use. It can be used in commercial and industrial areas. It can save the car from being smashed.

5. Retro-Reflective

It has the longest photoelectric sensing distance. It has a sensor monitoring range of up to 10m. It works the same as through-beam, but the emitter and receiver are located in the same housing, facing the same direction. Emitter produces laser and projects it towards reflector, which deflects beam back to the receiver. When the light path occurs or disturbed, detection happens. It saves cost and time. Reflective objects like cans or mirrors are challenging for retro-reflective sensors. This will cause erroneous output because the target reflects light to trick the receiver that the beam was not interrupted.

6. Ultrasonic Sensor

It consists of three components such as a transmitter, receiver and trans receiver. Transmitter converts -> electrical signal into ultrasound, the receiver converts->ultrasound into an electrical signal, and trans receiver can transmit and receive ultrasound. It can be used to measure the tank’s fluid level, speed through the water. To measure the tank’s fluid level sensor measures distance to the surface of the fluid. It can be used in automated production processes. It can detect within a specified sensing distance by measuring propagation time. This sensor is best suited for applications that require detection of the continuous object.

Benefits of Proximity Sensors

Some of the benefits are given below:

  • Inductive proximity sensors are accurate, high switching rates and can work in a difficult environment.
  • Capacitive sensors can detect metallic and non-metallic objects. It is having high speed and low cost.
  • The ultrasonic sensor has more sensing distance other than other sensor types.
  • The photoelectric sensor can sense any type of material with long life and fast response time.
  • It can be used in mobile devices like; when we handle calls, it will detect that the screen should be off while answering the call; this will avoid dialing numbers.
  • It can be used while parking the car; it will detect the area safer to stop or park the car.

Conclusion

We have learned what proximity sensors and the use of them in real-time is. It can detect the object without touching it; this makes our life easier because it gives us an alert if sensors detect the object. Different types of sensors work differently in different areas. It is working is based on coil and oscillator.
