Introduction to Data Link Layer
Data Link Layer is the second layer of the OSI model and lies between the physical layer and the network layer. OSI or in other words, Open Systems Interconnection model is a conceptual model which is used vastly in the software industry especially in the field of communication for characterizing and standardizing the functions without touching the internal structure underlying in the structure or technology. This layer in the OSI model defines the protocol for establishment as well as the termination of a connection between two devices. This layer is subdivided into 2 sublayers namely, Medium Access control and Logical Link Control. In the below few sections we will look in detail on these 2 sublayers as well as other components.
Layers of the OSI Model
In the previous section, we already had a glimpse of what the OSI model is, now let us see what the other layers in this conceptual model are. The 7 layers of the OSI model are:
- Physical Layer
- Data Link layer
- Network Layer
- Transport Layer
- Session Layer
- Presentation Layer
- Application Layer
Now looking into the sublayers of data link layer, i.e. Medium Access Control (MAC) which helps in controlling the hardware responsible for interaction with the transmission mediums and the Logical Link Control (LLC) which acts as a connection between MAC sublayer and the network layer and uses multiplexing mechanism for allowing several network protocols to coexist within a multipoint network. The division into sub layer is to bring in the concept of modularity for standardized practice.
The main functionality of the Data link layer is the transfer of datagram across an individual link. Now in this statement, we came across two new terminologies and let us look briefly into those first before proceeding ahead. One of the terms is Link, Link is the communication channel through which adjacent nodes are connected. For the other term “Datagram” let us understand it from an analogous situation. Now let us prepare an itinerary from Bangalore to some remote place in West Bengal. The entire travel will involve 3 basic transportation i.e. flights, trains, and a bus. Now, these three modes of transportation are independent of each other and we assume the link to be direct in nature but performs a basic service of moving you from one location to its adjacent location so that you can take the next service. In this analogy, the one who is traveling is the datagram, each of the transportation segments the traveler is traveling is analogous to links and each mode used is the link-layer protocol.
Services of Data Link Layer
Now we have a fair idea on what links, datagrams are and at a higher level what is a data link layer, let us look into the aspects and the services provided by them which will encapsulate the importance of the data link layer in OSI model. In a nutshell, we have 6 services which Data Link layer provide, and they are:
1. Framing & Link Access
Even before the transmission starts each network frame is encapsulated by the layer protocols. Earlier we discussed about the frame which consists of a number of data fields and each data field comprising of datagrams inserted. The structure of the frame is specified here along with the channel access protocol which would be used for transmitting the frame over the link.
2. Flow Control
The stations through which the transmission happens might have different speed or capacity and this layer ensures that the flow of data works at the same speed for exchanging data. In case the flow is not controlled the recipient buffer might overflow leading to loss of frames.
3. Reliable Delivery
Talking about transmission is incomplete without talking about reliable delivery service and that is where the Data Link layer accomplishes that through the concept of transmissions and acknowledgments. Typically, we encounter the problem of flipped bits of a problem in the transmission. The errors are detected locally, and an attempt is taken to recover the original data along with the error reporting mechanism to the sender.
4. Half-Duplex & Full-Duplex
This characteristic of this is to provide flexibility in the transmission of data. In a full-duplex mode both the nodes would be able to transmit data simultaneously and in a half-duplex mode, only one node would be able to transmit data at the same time.
5. Error Detection
In error detection, Data Link Layers provides the functionality of providing a mechanism for detecting one or more error that might have occurred by signal attenuation or noise. This detection functionality is possible by using error detection bits in the frame which is getting transmitted and based on the bits can perform an error check.
The functionality of multi-access is of high importance as it avoids the collision which might occur due to the host on a shared link trying to share data. The mechanism of CSMA/CD is deployed for allowing access to shared media among multiple systems.
Advantages of Data Link layer
In the previous sections, we have holistically touched on different aspects of Data Link Layer and dived deep into the importance or feature it provides.
- Since the OSI model is very generic, having a standardized model helps in integration without much hassle.
- Having hidden protocols allows any protocols implementation and has the flexibility to adapt with many protocols.
- It provides a connection through connection-oriented methods as well as connectionless services. Connection services are used when we need high reliability and speed is not of much concern and vice versa requirement for the connectionless transmission.
- Since there are so many functionalities around error detection and reliable delivery the messages don’t arrive out of order.
In this article, we have had an overall deep dive into Data Link Layer wherein we started by introducing what it is. In conclusion, it is responsible for the conversion of data streams into signals bit by bit, and at the end, the signals are picked and assembled into a recognizable frame format.
