Aluminum Stamping: Overview
Aluminum is a lightweight, high-strength material used across various industries. Manufacturers use various methods to convert raw aluminum into desired components, and aluminum sheet metal stamping is one key technique. It involves using stamping presses, dies, and punches to perform various metal-forming operations. Understanding aluminum alloys, die tooling, forming operations, and other aspects of aluminum stamping helps to develop better stamping strategies and achieve optimal results. The upcoming sections of the article will discuss material options, stamping types, aluminum stamping methods, advantages, and application examples.
What are the Aluminum Stamping Grades?
You can use aluminum sheets of different alloy grades, including series 1xxx, 2xxx, 3xxx, 4xxx, 5xxx, 6xxx, 7xxx, and 8xxx. The thickness limit is up to 6mm, but it can be thicker. Moreover, 1100, 3003, 5054, and 5052 aluminum stamping grades are the most common in metal fabrication. The table below outlines the aluminum stamping grades with their key properties:
| Alloy Series | Stamping Grades | Key Properties |
| 1xxx | 1050, 1100 | ≥99% Al, excellent formability, high conductivity, excellent corrosion resistance, low strength |
| 2xxx | 2011, 2024 | Al–Cu, high strength, heat-treatable, poorer corrosion resistance, lower forming ductility |
| 3xxx | 3003, 3105 | Al–Mn, moderate strength, excellent formability, good corrosion resistance, weldability |
| 4xxx | 4032, 4043 | Al–Si, good fluidity/wear resistance, lower melting point, fair formability, brazing-friendly |
| 5xxx | 5052, 5083, 5054 | Al–Mg, moderate strength, excellent corrosion resistance, good weldability &formability |
| 6xxx | 6061, 6063 | Al–Mg–Si, heat-treatable, good strength-to-weight, extrudable, fair formability |
| 7xxx | 7075, 7010 | Al–Zn, very high strength, heat-treatable, limited formability, poorer corrosion resistance |
| 8xxx | 8006, 8090 | Speciality alloys (Li, Fe, etc.), high strength/corrosion resistance |
Aluminum Stamping Operations
Metal stamping is known for its ability to perform multiple metal-forming operations simultaneously. It includes sheet metal bending, punching, blanking, deep drawing, embossing, coining, and other processes. All of these operations are carried out with aluminum stamping dies and presses, along with other tooling components.
Common operations include:
- Bending: The process of bending an aluminum sheet from a fixed line to form a desired angle or curvature.
- Punching: This operation uses a punch that strikes the sheet at high pressure against a punching die to create a hole and related features.
- Blanking: It is similar to punching, except that the punch-out section of the metal sheet is the desired part in the blanking process.
- Deep Drawing: Deep drawing stretches the aluminum sheet into the die cavity by pressing the punches, resulting in deep-drawn shapes.
- Embossing: This forming operation uses press-stamping tools to create raised letters, symbols, and custom patterns on aluminum sheets.
- Coining: Coining uses extremely high pressure to plastically deform metal within closed dies, imprinting letters, symbols, or other designs.
Types of Aluminum Stamping Methods
You can use any of the following aluminum stamping methods based on the complexity and design specifications of the desired parts.
1. Progressive Die Tooling
As the name suggests, progressive die tooling involves multiple die-punch stations in a series. The setup feeds the worksheet and advances it after each operation. This approach is ideal for efficiently producing large quantities of intricate aluminum components.
2. Multi-Slide Stamping
This stamping method uses four or more sliding tools. The horizontally driven slides bend, shear, and form the metal strip (or wire) into small, intricate parts in a single run. Examples of aluminum multislide-stamped parts include brackets, clips, and heat-sink fins.
3. Transfer Die Stamping
Transfer die stamping involves mechanically moving the worksheet from one stamping station to the next. Each station forms a shape or feature on a section of the metal sheet, producing complex parts at the end. This is typically suitable for large sizes of metal sheets.
4. Fine Blank Stamping
Fine blanking creates sheet metal parts with clean edges and very accurate sizes. It is ideal for small parts that need high precision.
Aluminum Stamping Advantages
Aluminum stamping offers several advantages, as follows:
- Edges of stamped aluminum parts are smooth and burr-free. You can further finish them with powder coating, plating, or other techniques.
- Stamping produces the same accurate dimensions even in large production runs.
- Aluminum alloys are highly formable and can be stamped into complex parts & products.
- It is cost-effective for medium to high production volumes.
- Aluminum’s electrical and thermal conductivity enable it to serve in electrical and heat-transfer applications.
- The stamped aluminum parts provide excellent corrosion and surface degradation resistance.
Applications of Aluminum Stamping
Aluminum stamping is commonly used in many industries to make different sheet-metal parts designed for specific uses. The table below shows how aluminum stamping is used in electronics, electrical, automotive, aerospace, and HVAC industries, along with examples of stamped aluminum parts.
| Industry | Why Aluminum Stamping? | Application Examples |
| Electronics | Lightweight, high-conductivity, low-cost enclosures | Heat sinks, device housings, plug shells, battery trays, PCB brackets |
| Electrical | Light, conductive, repeatable items | Busbars, terminal lugs, grounding brackets, switch plates |
| Automotive | Strong, lightweight, fuel-efficient | Heat shields, door panels, engine mounts, EV trays, hood panels |
| Aerospace | Lightweight, fatigue-resistant, corrosion-proof | Wing ribs, avionics housings, seat frames, fittings |
| HVAC | Conductive, corrosion-resistant, highly formable | Condenser fins, compressor plates, fan blades, housings, headers, duct brackets |
Final Thoughts
Aluminum stamping is an accurate, quick, and affordable way to make complex sheet-metal parts. This flexible process can be used to produce both standard and custom aluminum stamping components. However, if you plan to outsource production rather than make parts in-house, choose a supplier that offers comprehensive sheet metal stamping services. These should include design support (DFM) and finishing for stamped aluminum parts.
